Valentine Moon.

Generative art example code.

About this creative coding work.

Creative coding work made with Processing.

It generates something like fruits and leaves under the pale light.
I used the De Jong attractor in Vector Field calculation. This method brings me an interesting result.

It's a derivation work of 'Rose Darling'.

This code does not display any images on the screen but generates image files in frames directory.

Processing code example.

Please feel free to use this example code.
To see other works based on my code is my pleasure. And my honor.


/**
 * Valentine Moon.
 *
 * @author @deconbatch
 * @version 0.1
 * Processing 3.2.1
 * created 2019.09.20
 * It generates something like fruits and leaves under the pale light.
 *
 *
 */

void setup() {

  size(980, 980);
  colorMode(HSB, 360, 100, 100, 100);
  smooth();

}

void draw() {

  int   imgMax  = 3;
  int   ptnMax  = 3;
  int   plotMax = 700;
  float hueInit = random(360.0);

  for (int imgCnt = 0; imgCnt < imgMax; ++imgCnt) {
    // shape parameters
    float paramA   = random(4.0, 5.0);
    float paramB   = random(1.0, 3.0);
    float paramC   = random(4.0, 5.0);
    float paramD   = random(1.0, 3.0);
    float plotMult = random(3.0, 4.0);
    float plotDiv  = random(0.0001, 0.0002);

    hueInit += 90.0;
    background(hueInit, 90.0, 20.0, 100);
    blendMode(LIGHTEST);
    noStroke();

    for (int ptnCnt = 0; ptnCnt < ptnMax; ++ptnCnt) {
      float ptnRatio = map(ptnCnt, 0, ptnMax, 0.0, 1.0);

      float initDiv = map(ptnRatio, 0.0, 1.0, 0.1, 0.05);
      float baseHue = hueInit + map(ptnRatio, 0.0, 1.0, 120.0, 0.0);
      float baseSiz = map(ptnRatio, 0.0, 1.0, 60.0, 30.0);

      // draw vector field
      for (float xInit = 0.0; xInit < 1.0; xInit += initDiv) {
        for (float yInit = 0.0; yInit < 1.0; yInit += initDiv) {
          float xPoint = xInit;
          float yPoint = yInit;
          for (int plotCnt = 0; plotCnt < plotMax; ++plotCnt) {
            float plotRatio = map(plotCnt, 0, plotMax, 0.0, 1.0);
            float sineRatio = sin(PI * plotRatio);

            float eHue = baseHue + plotRatio * 30.0 + noise(xInit, yInit) * 60.0;
            float eSat = map(sineRatio, 0.0, 1.0, 100.0, 10.0);
            float eBri = map(sineRatio, 0.0, 1.0, 100.0, 0.0);
            float eSiz = baseSiz * sineRatio;

            float xPrev = xPoint;
            float yPrev = yPoint;
            xPoint += plotDiv * (sin(TWO_PI * paramA * yPrev * plotMult) - cos(TWO_PI * paramB * xPrev * plotMult));
            yPoint += plotDiv * (sin(TWO_PI * paramC * xPrev * plotMult) - cos(TWO_PI * paramD * yPrev * plotMult));

            fill(eHue % 360.0, eSat, eBri, 80.0);
            ellipse(xPoint * width, yPoint * height, eSiz, eSiz);
          }
        }
      }
    }

    casing();
    saveFrame("frames/" + String.format("%04d", imgCnt + 1) + ".png");

  }
  exit();

}

/**
 * casing : draw fancy casing
 */
private void casing() {
  blendMode(BLEND);
  fill(0.0, 0.0, 0.0, 0.0);
  strokeWeight(60.0);
  stroke(0.0, 0.0, 0.0, 100.0);
  rect(0.0, 0.0, width, height);
  strokeWeight(50.0);
  stroke(0.0, 0.0, 100.0, 100.0);
  rect(0.0, 0.0, width, height);
}


/*
Copyright (C) 2019- deconbatch

This program is free software: you can redistribute it and/or modify
it under the terms of the GNU General Public License as published by
the Free Software Foundation; either version 3 of the License, or
(at your option) any later version.

This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
GNU General Public License for more details.

You should have received a copy of the GNU General Public License
along with this program.  If not, see
*/





Yet another artwork examples.

Generative art example code.
Generative art example code.
